Return Bend Ring Loader

Short Description:

The machine is used to load welding ring onto return bend automatically, which will then go through automated brazing. It is widely used in copper tubes in HVACR industry. The ring loader is fully automatic, simple to operate and productive.

Key Features:

1.High degree of automation

2.Convenient operation, exquisite appearance

3.Scale board on servo motor, accurate positioning

4.PLC & touch screen integrated control

5.Device for smoothing the tube end.

PRODUCT SPECIFICATION:

Parameter	Value
Material processable	Copper, Aluminum
Tube diameter	Φ5mm-Φ12.7mm
Tube Thickness	0.41~0.8mm
Efficiency	50times/minute
Tolerance	±1.0 mm
Power supply	3ph. 380V 50Hz
Total Power	2.5kW
Total Power	2.5kW

Where can you ship this equipment to globally?

Anywhere you desire. We have customers based in many nations in every continents, to name a few: Canada, the USA, Mexico, Brazil, France, Germany, Poland, Russia, Egypt, Algeria, Saudi Arabia, India, Thailand, Korea.

How can I get after service from China during and after Covid?

We have worldwide after service teams based in Europe, Middle East, North America, and South Asia that is able to support our global customers. We also host a multi-lingual speaking team that can provide remote technical support and service from China. When traveling limitation is limited, our technicians can fly to you if necessary.

What is the general leadtime?

In-stock machines takes around 10 days to deliver. Standard configuration machines take around 45 to 90 days to deliver. The lead time depends on the size, complexity and destination standards.

What is the standard of your machine?

JDM provides CE standard products with CE marks. If required, we can make UL standard products as well.

How do I know you make good quality machines?

We have dedicated engineering team, quality team, precise machine tools and ISO9000 Quality system in the company. We provide WEBEX online inspection and onsite checking for customer to inspect the manufacturing.

What payment and delivery terms do you accept?

JDM accepts L/C, T/T, Western Union and Cash Payment. We accept EXW, FOB, CIF and other shipping terms.
